| evel of security |
IP42 |
| Working temperature (° C) |
-30 … + 60 |
| Dimensions (height x width x depth) mm |
170x35x21 |
| Power consumption max (A) |
0.3 |
| Supply voltage (V) |
12VDC |
| Maximum load capacity [kg] |
135 |
| Strength [N] |
300 |
| Dimension of the electromagnet width [mm] |
35 |
| Dimension of electromagnet length [mm] |
170 |
| Dimension of electromagnet height [mm] |
21 |
| Dimension yoke width [mm] |
33 |
| Yoke dimension length [mm] |
133 |
| Dimension yoke height [mm] |
11 |
| Weight |
0.7 kg |
