| Camera |
| Image Sensor |
1/2.8″ STARVIS™ CMOS |
| Pixel |
4MP |
| Max. Resolution |
2560 (H) × 1440 (V) |
| ROM |
4GB |
| RAM |
1GB |
| Electronic Shutter Speed |
1/3–1/30000s |
| Scanning System |
Progressive |
| Min. Illumination |
Color: 0.005Lux@F1.6
B/W: 0.0005Lux@F1.6
0Lux (IR light on) |
| Illumination Distance |
150 m (492.13 ft) |
| Illuminator On/Off Control |
Zoom Prio/Manual/SmartIR |
| Illuminator Number |
4 |
| Lens |
| Focal Length |
3.95 mm–177.7 mm |
| Max. Aperture |
F1.6–F4.95 |
| Field of View |
H: 70.3°–1.8°; V: 37°–1°; D: 69.3°–2° |
| Optical Zoom |
45x |
| Focus Control |
Auto/Semi-Auto/Manual |
| Close Focus Distance |
0.01 m–3 m |
| Iris Control |
Auto/Manual |
| DORI Distance |
Detect |
Observe |
Recognize |
Identify |
| 3176 m
(10419.95 ft) |
1270 m (4166.67 ft) |
635 m (2083.33 ft) |
317 m (1040.03 ft) |
| PTZ |
| Pan/Tilt Range |
Pan: 0°–360°; Tilt: -15°–+90° |
| Manual Control Speed |
Pan: 0.1°/s–300°/s; Tilt: 0.1°/s–200°/s |
| Preset Speed |
Pan: 400°/s; Tilt: 300°/s |
| Presets |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Pattern |
5 |
| Scan |
5 |
| Speed Adjustment |
Support |
| Power-off Memory |
Support |
| Idle Motion |
Preset/Tour/Pattern/Scanning |
| Protocol |
DH-SD
Pelco-P/D(Auto recognition) |
| General Intelligence |
| Event Trigger |
Motion detection, video tampering, scene changing, Network disconnection, IP address conflict, illegal access, and storage anomaly. |
| IVS |
Object Abandoned/Missing |
| Artificial Intelligence |
| Perimeter Protection |
Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc. |
| SMD Plus |
Support |
| Auto Tracking |
Support |
| Face Detection |
Support |
| Smart Capture |
Support human, motor vehicle and non-motor vehicle image capture. |
| Video |
| Compression |
H.265/H.265+/H.264+/H.264/MJPEG(Sub Stream) |
| Streaming Capability |
3 Streams |
| Resolution |
4M (2560×1440); 3M (2048×1536); 1080P (1920×1080); 1.3M (1280×960); 720P (1280×720); D1 (704×576/704×480); CIF (352×288/352×240) |
| Frame Rate |
Main stream: 4M/3M(1–25/30fps), 1080P/1.3M/720P(1–25/30fps)
Sub stream 1: D1/CIF(1–25/30fps)
Sub stream 2: 1080P(1-20/11fps),
1.3M/720P(1–25/30fps), D1/ CIF(1–25/30fps) |
| Bit Rate Control |
Variable/Constant |
| Bit Rate |
H.264: 32 Kbps–8192 Kbps
H.265: 32 Kbps–8192 Kbps |
| Day/Night |
Support |
| BLC |
Support |
| WDR |
120dB |
| HLC |
Support |
| White Balance |
Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural/Street lamp |
| Gain Control |
Auto/Manual |
| Noise Reduction |
2D/3D |
| Motion Detection |
Support |
| Region of Interest (RoI) |
Support |
| Image Stabilization |
Electronic |
| Defog |
Electronic |
| Digital Zoom |
16x |
| Flip |
0°/180° |
| Privacy Masking |
Up to 24 areas |
| Certification |
| Certifications |
CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB,ANSI C63.4- 2014 |
| Audio |
| Compression |
G.711A; G.711Mu; G.726; AAC; G.722.1; G.723; G.729; PCM; MPEG2-Layer2 |
| Port |
| Audio Input |
1 (LINE IN; bare wire) |
| Audio Output |
1 (LINE OUT; bare wire) |
| Alarm I/O |
2/1 |
| Network |
| Ethernet |
1 RJ-45 Port 10/100Base-T |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3(MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP |
| Interoperability |
ONVIF Profile S&G&T; CGI |
| Streaming Method |
Unicast/Multicast |
| User/Host |
20 (Total bandwidth 48M) |
| Storage |
FTP; Micro SD card (256G); P2P |
| Browser |
IE7 and newer versions
Chrome 42 and older versions
Firefox 52 and older versions
Safari |
| Management Software |
Smart Player
Smart PSS
DSS
Easy4ip |
| Mobile Phone |
IOS/Android/Windows Phone |
| Power |
| Power Supply |
AC24V/3A±25%
PoE+(802.3at) |
| Power Consumption |
11W
20W (IR light on) |
| Environment |
| Operating Conditions |
–40°C to +70°C (–40°F to +158°F) |
| Operating Humidity |
≤95%RH |
| Protection |
IP67; IK10; TVS 6000V lightning protection;
surge protection |
| Structure |
| Dimensions |
Φ190 mm×332 mm (7.48″×13.07″) |
| Weight |
Net Weight: 4.7 kg (10.36 lb)
Gross Weight: 8 kg (17.64 lb) |
| Casing |
Metal |
