Pagrindinės savybės
> 1/1.8” 4Megapixel progressive scan CMOS
> H.265 & H.264 triple-stream encoding
> 25/30 fps@2688 × 1520, 50/60 fps@1080 (1920 × 1080)
> WDR (140 dB), Day/Night (Electronic), 3D DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS
> 3.6 mm fixed lens
> 1/1 Alarm in/out, 1/1 audio in/out
> Micro SD memory, IP67
Techniniai parametrai
| Camera |
| Image Sensor |
1/1.8” 4Megapixel progressive scan CMOS |
| Effective Pixels |
2688 (H) × 1520 (V) |
| RAM/ROM |
1 GB/128 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual, 1/3 s–1/100000 s |
| Minimum Illumination |
0.001 Lux @F1.0 |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
Board-in |
| Focal Length |
3.6 mm |
| Max. Aperture |
F1.0 |
| Angle of View |
H: 93°, V: 50° |
| Aperture Type |
Fixed |
| Close Focus Distance |
2.0 m (6.56 ft) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| 3.6mm |
70 m (230 ft) |
28 m (91 ft) |
14m(46ft) |
7m(23ft) |
| Pan/Tilt/Rotation |
| Pan/Tilt/Rotation Range |
Pan: 0˚–360˚; Tilt: 0˚–90˚; Rotation: 0˚–360˚ |
| Artificial Intelligence |
| Face Detection |
Support face image capture |
| Perimeter Protection |
Tripwire; intrusion (Recognition of vehicle and people); fast moving; loitering detection; parking detection and people gathering |
| People Counting |
Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection |
| General Intelligence |
| Event Trigger |
Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly |
| General Intelligence |
Object Abandoned/Missing |
| Heat Map |
Yes |
| Video |
| Compression |
H.265, H.264, H.264B, H.264H,
MJPEG(sub stream) |
| Smart Codec |
Yes |
| Streaming Capability |
3 Streams |
| Resolution |
2688 × 1520/2560 × 1440/2304 × 1296/1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) |
| Frame Rate |
Main Stream: 2688 × 1520 (1 fps–25/30 fps)
2560 × 1440 (1 fps–25/30 fps)
1920 × 1080 (1 fps–50/60 fps) |
| Sub Stream: D1 (1 fps–25/30 fps)
D1 (1 fps–50/60 fps) |
| Third Stream: 1080P (1 fps–16 fps) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 32 Kbps–8192 Kbps
H.265: 19 Kbps–8192 Kbps |
| Day/Night |
Day/Night: Electronic
Color/B/W |
| BLC Mode |
BLC/HLC/WDR (140 dB)/SSA |
| White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detetion |
Off/On (4 Zone, Rectangle) |
| Region of Interest |
Off/On (4 Zone) |
| Defog |
Yes |
| Flip |
0°/90°/180°/270° |
| Mirror |
Off/On |
| Privacy Masking |
Off/On (4 Area, Rectangle) |
| Audio |
| Compression |
G.711a, G.711Mu, G.726, AAC, G.723 |
| Network |
| Ethernet |
RJ-45 (10/100 Base-T) |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; Milstone, Genetec; P2P |
| Streaming Method |
Unicast/Multicast |
| Max. User Access |
20 Users |
| Edge Storage |
NAS; FTP; SFTP
Micro SD card 256 GB |
| Web Viewer |
IE (versions newer than IE8), Chrome,
Firefox, Safari (versions newer than Safari 12) |
| Management Software |
Smart PSS, DSS, P2P |
| Smart Phone |
iOS, Android |
| Certifications |
| Certifications |
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Interface |
| Audio Interface |
1/1 channel In/Out |
| Alarm |
1 channel In: 5mA 5V DC
1 channel Out: 300mA 12V DC |
| Electrical |
| Power Supply |
DC 12V (±30%), PoE (802.3af) (Class 0) |
| Power Consumption |
<4.4W |
| Environmental |
| Operating Conditions |
-30° C to +60° C (-22° F to +140° F)/Less than 95% RH |
| Storage Conditions |
-30° C to +60° C (-22° F to +140° F) |
| Ingress Protection |
IP67 |
| Construction |
| Casing |
Metal |
| Dimensions |
244.1 mm × 79.0 mm × 75.9 mm (9.61” × 3.11” × 2.99”) |
| Net Weight |
0.805 Kg (1.77 lb) |
| Gross Weight |
1.16 Kg (2.56 lb) |
