Pagrindinės savybės
> 4MP, 1/3” CMOS image sensor,low illuminance, high image definition
> Outputs 4MP (2560 × 1440)@25/30 fps, max. supports 4MP (2688 × 1520)@20 fps
> H.265 codec, high compression rate, ultra-low bit rate
> Built-in IR LED, max IR distance: 40 m
> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire
> Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnected, IP conflict, illegal access, voltage detection
> Supports max. 256 GB Micro SD card
> 12V DC/PoE power support
> IP67 protection
Techniniai parametrai
| Camera |
| Image Sensor |
1/3” 4Megapixel progressive CMOS |
| Effective Pixels |
2688 (H) × 1520 (V) |
| ROM |
128 MB |
| RAM |
128 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
| Min. Illumination |
0.008 Lux@F1.5 |
| IR Distance |
40 m (131.23 ft) |
| IR On/Off Control |
Auto/Manual |
| IR LEDs Number |
2 |
| Pan/Tilt/Rotation Range |
Horizonal: 0°–355°
Vertical: 0°–78°
Rotation: 0°–360° |
| Lens |
| Lens Type |
Motorized vari-focal |
| Mount Type |
φ14 |
| Focal Length |
2.7 mm–13.5 mm |
| Max. Aperture |
F1.5 |
| Field of View |
Horizonal: 104°–27°
Vertical: 55°–15°
Diagonal: 124°–31° |
| Iris Type |
Fixed aperture |
| Close Focus Distance |
0.8 m–0.8 m (2.62 ft–2.62 ft) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| W |
64 m
(209.97 ft) |
25.6 m
(83.99 ft) |
12.8 m
(41.99 ft) |
6.4 m
(21.00 ft) |
| T |
220 m
(721.78 ft) |
88 m
(288.71 ft) |
44 m
(144.36 ft) |
22 m
(72.18 ft) |
| Smart Event |
| General IVS Analytics |
Intrusion; tripwire |
| Video |
| Video Compression |
H.265; H.264; H.264B; MJPEG |
| Smart Codec |
Yes |
| Video Frame Rate |
Main stream:
2688 × 1520 (1 fps-20 fps)
2560 × 1440 (1 fps-25/30 fps)
Sub stream:
704 × 576 (1 fps-25 fps)
704 × 480 (1 fps-30 fps) |
| Stream Capability |
2 streams |
| Resolution |
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps |
| Day/Night |
Auto(ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest(RoI) |
Yes (4 areas) |
| Smart IR |
Yes |
| Image Rotation |
0°/90°/180°/270° (Supports 90°/270° with 2688 × 1520 resolution.) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Network |
| Network |
RJ-45 (10/100 Base-T) |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour |
| Interoperability |
ONVIF(Profile S/Profile G/Profile T);CGI; P2P; Milestone; Genetec |
| User/Host |
20 |
| Edge Storage |
Cloud; FTP; SFTP; Micro SD Card (support max. 256 GB); NAS |
| Browser |
IE
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
IOS; Android |
| Certification |
| Certifications |
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Power |
| Power Supply |
12V DC/PoE (802.3af) |
| Power Consumption |
< 6.4W |
| Environment |
| Operating Conditions |
-30°C to +60°C (-22°F to +140°F)/less than ≤ 95% |
| Storage Temperature |
-40°C to +60°C (-40°F to +140°F) |
| Protection |
IP67 |
| Structure |
| Casing |
Metal |
| Dimensions |
108.3 mm × Φ122 mm (4.26″ × Φ1.80″) |
| Net Weight |
0.69 kg (1.52 lb) |
| Gross Weight |
0.88 kg (1.94 lb) |
