Pagrindinės savybės
> 1/2.8” 2Megapixel progressive scan STARVIS™ CMOS
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
> 25/30 fps@1080P (1920 × 1080)
> WDR (120 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS (DSS/PSS) & DMSS
> 2.7 mm–13.5 mm motorized lens
> 1/1 Alarm in/out, 1/1 audio in/out
> Max. IR LEDs Length 40 m
> Micro SD memory, IP67, IK10
Techniniai parametrai
| Camera |
| Image Sensor |
1/2.8” 2Megapixel progressive scan STARVIS™ CMOS |
| Max. Resolution |
1920 (H) × 1080 (V) |
| RAM/ROM |
512 MB/128 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual, 1/3 s–1/100000 s |
| S/N Ratio |
> 56 dB |
| Minimum Illumination |
0.002 Lux@F1.5 |
| Illumination Distance |
Distance up to 40 m (131 ft) |
| Illuminator On/Off Control |
Auto/Manual |
| Illuminator Number |
3 (IR LED) |
| Lens |
| Lens Type |
Motorized vari-focal |
| Mount Type |
Board-in |
| Focal Length |
2.7 mm–13.5 mm |
| Max. Aperture |
F1.5 |
| Angle of View |
H: 109°–30°, V: 57°–17° |
| Aperture Type |
Auto |
| Close Focus Distance |
0.8 m (2.62 ft) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| W |
44m(144ft) |
18m(59ft) |
9m(30ft) |
4m(13ft) |
| T |
146m(479ft) |
58m(190ft) |
29m(95ft) |
15m(49ft) |
| Pan/Tilt/Rotation |
| Pan/Tilt/Rotation Range |
Pan: 0˚–355˚; Tilt: 0˚–65˚; Rotation: 0˚–355˚ |
| Artificial Intelligence |
| Face Detection |
Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: face, single inch photo;three snapshot methods: real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting |
| Perimeter Protection |
Tripwire; intrusion; fast moving (the three functions
support the classification and accurate detection
of vehicle and human); loitering detection; people
gathering; parking detection |
| People Counting |
Support the counting of enter number, leave
number, and pass number, and displaying and
outputting yearly/monthly/daily reports.
Support the counting of number in area, and 4 rules
configuration. Count number of people or stay time
and link alarm.
Support queue management, and 4 rules
configuration. Count number of people or stay time
and link alarm |
| General Intelligence |
| Event Trigger |
Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly |
| General Intelligence |
Object Abandoned/Missing |
| Heat Map |
Yes |
| Video |
| Compression |
H.265,H.264,H.264B,H.264H,
MJPEG (only supported by sub stream) |
| Smart Codec |
Smart H.265+/ Smart H.264+ |
| Streaming Capability |
3 Streams |
| Resolution |
1080P (1920 × 1080)/1.3M (1280 × 960)/720P (1280 × 720)/D1 (704 × 576/704 × 480)/VGA (640 × 480)/CIF (352 × 288/352 × 240) |
| Frame Rate |
Main Stream: 1080P (1 fps–25/30 fps) |
| Sub Stream: D1 (1 fps–25/30 fps) |
| Third Stream: 1080P (1 fps–6 fps) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 32 Kbps–8192 Kbps
H.265: 19 Kbps–7424 Kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC Mode |
BLC/HLC/WDR (120 dB) |
| White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detection |
Off/On (4 Zone, Rectangle) |
| Region of Interest |
Off/On (4 Zone) |
| Electronic Image Stabilization (EIS) |
Yes |
| Smart Illumination |
Yes |
| Defog |
Yes |
| Flip |
0°/90°/180°/270° |
| Mirror |
Off/On |
| Privacy Masking |
Off/On (4 Area, Rectangle) |
| Audio |
| Audio Compression |
G.711a, G.711Mu, G.726, AAC, G.723 |
| Alarm |
| Alarm Event |
No SD card;SD card full;SD card error;network disconnection;IP conflict;illegal access;motion detection;video tampering;Defocus Detection;scene changing;intrusion;tripwire;abandoned object;missing object;fast moving;parking detection;loitering detection;people gathering;audio detection;people counting;face detection;People counting in area;Stay alarm;People No. exception detection;Queue Management |
| Network |
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Protocol |
IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T), CGI, Milstone, Genetec, P2P |
| User/Host |
20 Users |
| Storage |
NAS;FTP;SFTP;Dahua Cloud
Micro SD card 256 GB |
| Browser |
IE (versions newer than IE8), Chrome,
Firefox, Safari (versions newer than Safari 12) |
| Management Software |
Smart PSS, DSS, DMSS |
| Mobile Phone |
iOS, Android |
| Certifications |
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Interface |
| Audio Interface |
1/1 channel In/Out |
| Alarm |
1 channel In: 5mA 5V DC
1 channel Out: 300mA 12V DC |
| Electrical |
| Power Supply |
DC 12V (±30%), AC 24V (±30%), PoE (802.3af) |
| Power Consumption |
<11.8W |
| Environmental |
| Operating Conditions |
-30° C to +60° C (-22° F to +140° F)/Less than 95% RH |
| Storage Conditions |
-40° C to +60° C (-40° F to +140° F) |
| Protection Grade |
IP67,IK10 |
| Construction |
| Casing |
Metal |
| Dimensions |
Φ159.0 mm × 117.9 mm (6.26” × 4.64”) |
| Net Weight |
0.95 kg (2.09 lb) |
| Gross Weight |
1.20 kg (2.65 lb) |
