Pagrindinės savybės
> 5 MP, 1/2.7” CMOS image sensor, low illuminance, high image definition
> Outputs max. 5MP (2592 × 1944)@20 fps
> H.265 codec, high compression rate, low bit rate
> Built-in IR LED, max. IR distance: 50 m
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments
> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes
> Intelligent detection: Intrusion, tripwire
> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection
> Supports max. 256 G Micro SD card, built-in Mic
> 12V DC/POE power support
> IP67, IK10 protection
> SMD Plus
Techniniai parametrai
Camera |
Image Sensor |
1/2.7”5 Megapixel progressive CMOS |
Effective Pixels |
2592 (H) ×1944 (V) |
ROM |
128 MB |
RAM |
512 MB |
Scanning System |
Progressive |
Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100000 s |
Min. Illumination |
0.005 Lux@F1.6 |
IR Distance |
50 m (164.0 ft) |
IR On/Off Control |
Auto/Manual |
IR LEDs Number |
8 (IR LEDs) |
Pan/Tilt/Rotation Range |
Horizontal: -30° to 30°; vertical: 0° to 80°;
rotation: 0° to 360° |
Lens |
Lens Type |
Fixed focal |
Mount Type |
M12 |
Focal Length |
2.8 mm; 3.6 mm; 6 mm |
Max. Aperture |
F1.6 |
Field of View |
2.8 mm: Horizontal: 98°; vertical: 72°; diagonal: 130°
3.6 mm: Horizontal: 80°; vertical: 59° ; diagonal: 106°
6 mm: Horizontal: 50°; vertical: 36°; diagonal: 64° |
Iris Type |
Fixed aperture |
Close Focus Distance |
2.8 mm: 0.9 m (3.0 ft)
3.6 mm: 1.6 m (5.3 ft)
6 mm: 3.2 m (10.5 ft) |
DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
2.8mm |
56.0 m
(183.7 ft) |
22.4 m
(73.5 ft) |
11.2 m
(36.8 ft) |
5.6 m
(18.4 ft) |
3.6mm |
80.0 m
(262.5 ft) |
32.0 m
(105.0 ft) |
16.0 m
(52.5 ft) |
8.0 m
(26.3 ft) |
6mm |
120.0 m (393.7 ft) |
48.0 m
(157.5 ft) |
24.0 m
(78.7 ft) |
12.0 m (39.4ft) |
Professional, Intelligent |
Perimeter Protection |
Tripwire; intrusion (Recognition of human and vehicle) |
Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
Video |
Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG |
Smart Codec |
Yes |
Video Frame Rate |
Main stream (2592 × 1944@1–20 fps)
(2688 × 1520@1–25/30 fps)
sub stream (704 × 576@1–25/30 fps)
third stream (1280 × 720@1–25/30 fps) |
Stream Capability |
3 streams |
Resolution |
5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
Bit Rate Control |
CBR/VBR |
Video Bit Rate |
H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps |
Day/Night |
Auto(ICR)/Color/B/W |
BLC |
Yes |
HLC |
Yes |
WDR |
120 dB |
White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
Gain Control |
Auto/Manual |
Noise Reduction |
3D DNR |
Motion Detection |
OFF/ON (4 areas, rectangular) |
Region of Interest(RoI) |
Yes (4 areas) |
Smart IR |
Yes |
Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution.) |
Mirror |
Yes |
Privacy Masking |
4 areas |
Audio |
Built-in MIC |
Yes |
Audio Compression |
G.711a; G.711Mu; G726; AAC |
Network |
Network |
RJ-45 (10/100 Base-T) |
Protocol |
IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;
RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP |
Interoperability |
ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec |
Scene Self-adaptation |
Yes |
User/Host |
20 (Total bandwidth: 64 M) |
Edge Storage |
FTP; SFTP;Micro SD Card (support max. 256 G);Cloud; NAS |
Browser |
IE: IE8, IE9, IE11
Chrome
Firefox |
Management Software |
Smart PSS, DSS, DMSS |
Mobile Phone |
IOS; Android |
Certification |
Certifications |
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B |
Power |
Power Supply |
12V DC/PoE (802.3af) |
Power Consumption |
<5.7W |
Environment |
Operating Conditions |
-40°C to +60°C (-40°F to +140°F)/ less than≤95% |
Strorage Conditions |
-40°C to +60°C (-40°F to +140°F) |
Ingress Protection |
IP67; IK10 |
Structure |
Casing |
Metal + Plastic |
Dimensions |
55 mm × Φ108.9 mm (2.2″ × Φ4.3″) |
Net Weight |
380 g (0.8 lb) |
Gross Weight |
520 g (1.1 lb) |
