| Pavadinimas |
Aprašymas |
| Veido atpažinimas ir palyginimas |
Taip |
| Veido atvaizdų biblioteka |
Up to 16 face picture libraries, with up to 500 face pictures in total (each picture ≤ 1 MB, total capacity ≤ 80 MB) |
| Veido atvaizdų palyginimas |
1-ch face picture comparison alarm (HD analog camera) |
| Melagindų signalų atpažinimas |
Up to 4-ch |
| Vaizdo suspaudimas |
H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Kodavimo raiška |
Main stream: 8 MP@8 fps/5 MP@12 fps/4 MP@15 fps/3 MP@18 fps 1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) *: 8 MP@8 fps is only available for channel 1. Sub-stream: WD1/4CIF/CIF@25 fps (P)/30 fps (N) |
| Vaizdo bitų greitis |
32 Kbps to 10 Mbps |
| Dvigubas srautas |
Support |
| Srauto tipas |
Video, Video & Audio |
| Garso suspaudimas |
G.711u |
| Garso bitų greitis |
64 Kbps |
| IP vaizdo išvestis |
4-ch (up to 12-ch) Up to 8 MP resolution IP enhanced mode on: 8-ch (up to 16-ch), each up to 4 Mbps Support H.265+/H.265/H.264+/H.264 IP cameras |
| ANaloginė vaizdo išvestis |
8-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HDTVI įvestis |
8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p@25 fps, 720p@60 fps, 720p@50 fps, 720p@30 fps, 720p@25 fps *: The 8 MP signal input is only available for channel 1. |
| AHD įvestis |
5 MP, 4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
| HDCVI įvestis |
4 MP, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps |
| CVBS įvestis |
PAL/NTSC |
| CVBS išvestis |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| HDMI/VGA išvestis |
1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz HDMI/VGA simultaneous output |
| Audio įvestis |
1-ch, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz HDMI/VGA simultaneous output |
| Audio išvestis |
1-ch, RCA (2.0 Vp-p, 1 KΩ)，4-ch via coaxial cable |
| Audio ryšys |
1-ch, RCA (Linear, 1 KΩ) |
| Abipusis garso ryšys |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Sinchroninis atkūrimas |
8-ch |
| Nuotolinis prisijungimas |
64 |
| Tinklo protokolas |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Tinklo sąsaja |
1, RJ45 10/100 Mbps self-adaptive Ethernet interface |
| SATA |
1 SATA interface |
| Talpa |
up to 10 TB capacity for each disk |
| Serijos sąsaja |
RS-485 (half-duplex) |
| USB sąsaja |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
| Aliarmo įvestis/išvestis |
N/A |
| Maitinimas |
12 VDC, 2 A |
| Suvartojimas (be HDD) |
≤ 15 W |
| Darbo temperatūra |
-10 °C to 55 °C (14 °F to 131 °F) |
| Darbo drėgmė |
10% to 90% |
| Matmenys (P × G × A) |
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| Svoris (be HDD) |
≤ 2 kg (4.4 lb) |
