Standard: |
AHD, HD-CVI, HD-TVI, PAL, TCP/IP |
Video inputs: |
32 pcs BNC – HD-TVI / AHD / HD-CVI / CVBS |
Video outputs: |
1 pcs HDMI 4K
1 pcs HDMI
1 pcs VGA
1 pcs CVBS – BNC socket |
Audio inputs: |
4 pcs CINCH |
Audio outputs: |
1 pcs CINCH |
Image compression method: |
H.265 / H.265 Pro+ / H.265 Pro / H.264+ / H.264 |
Number of compression levels: |
6 |
Image records resolutions: |
- HD-TVI :
8 Mpx – 3840 x 2160 ,
5 Mpx – 2592 x 1944
4 Mpx – 2560 x 1440
3 Mpx – 1920 x 1536
1080p – 1920 x 1080
720p – 1280 x 720
- AHD :
5 Mpx – 2592 x 1944 ,
4 Mpx – 2560 x 1440
1080p – 1920 x 1080
720p – 1280 x 720
- HD-CVI :
4 Mpx – 2560 x 1440 ,
1080p – 1920 x 1080
720p – 1280 x 720
- CVBS :
960H – 960 x 576
- IP :
max. 8.3 Mpx – 3840 x 2160 px
|
Recording speed adjustment: |
8 Mpx IP @ 1 … 25 fps
8 Mpx @ 1 … 8 fps
5 Mpx @ 1 … 12 fps
4 Mpx @ 1 … 15 fps
3 Mpx @ 1 … 18 fps
1080p @ 1 … 25 fps
720p @ 1 … 25 fps
960H @ 1 … 25 fps
for each channel |
Operation modes: |
32 x AHD / HD-CVI / HD-TVI / CVBS / IP + 16 x IP |
Recording modes: |
Manual, Sensor, Motion detection, Schedule |
Supported hard drives: |
4 x 10 TB SATA + 1 x eSATA ,
Raid 0/1/5/6/10 |
External storage devices backup: |
Backup to USB drive (pendrive) |
Searching and playback the records: |
Records searching: timeline or file list. Playback: forward, fast, slow.
Playback max. 16 cameras in the same time |
Network interface: |
2 x RJ-45 – 10/100/1000 Base-T |
Network functions: |
Network Client Software and IE browser: live view, playback and backup of the records, partial configuration of the recorder parameters |
Network protocols: |
TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SNMP, NFS, iSCSI, UPnP, HTTPS, ONVIF |
USB: |
- 1 pcs USB 3.0
- 2 pcs USB 2.0
|
Mobile phones support: |
Port no.: 8000 or access by a cloud (P2P)
Android: Free application iVMS-4500
iOS (iPhone): Free application iVMS-4500 |
Default IP address: |
DHCP or 192.168.1.64 |
Default admin user / password: |
admin / –
The administrator password should be set at the first start |
Web browser access ports: |
80 |
PC client access ports: |
554 RTSP, 8000 |
Mobile client access ports: |
8000 |
Port ONVIF: |
80 |
RTSP URL: |
- rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no01/ – Main stream
- rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no02/ – Sub stream
|
Alarm inputs / outputs: |
16 / 4 |
PTZ control: |
- Control compatible with coax HD-TVI Hikvision
- RS-485 – Many protocols
|
Motion Detection: |
- Split the screen into zones : 22 x 18 motion zones
|
Main features: |
- Intelligent Image Analysis : crossing the line (tripwire), intrusion, people counting
- Heat map – the selection in the image by corresponding colors the areas with different traffic
- RS-232 interface
|
Mouse support: |
|
IR remote controller in the set: |
|
Power supply: |
100 … 240 V AC |
Color: |
Black |
Weight: |
5.4 kg |
Dimensions: |
440 x 405 x 75 mm |
Supported languages: |
Polish, English, Bulgarian, Croatian, Czech, Danish, Estonian, Greek, Spanish, Dutch, German, Norwegian, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Hungarian, Italian |
