| Sensorius |
1/3″ Progressive Scan CMOS |
| Min. apšvietimas |
Color: 0.01 Lux @(F1.2, AGC ON), 0.018 Lux @ (F1.6, AGC ON) |
| Užrakto greitis |
1/3 s to 1/100, 000 s, support slow shutter |
| Objektyvas |
2.8 to 12 mm |
| FOV |
Horizontal field of view: 98° to 28° Vertical field of view: 51° to 16° Diagonal field of view: 115° to 32° |
| Fokusavimas |
Auto |
| Objektyvo montavimas |
Φ14 |
| Diena / naktis |
IR cut filter |
| Reguliavimas |
Pan: 0° to 360°, tilt: 0° to 90°, rotation: 0° to 360° |
| Skaitmeninis triukšmo slopinimas |
3D DNR |
| Platus dinaminis diapazonas |
120dB |
| Vaizdo suspaudimas |
Main stream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG |
| H.264 tipas |
Baseline Profile/Main Profile/High Profile |
| H.264+ |
Main stream supports |
| H.265 tipas |
Main Profile |
| H.265+ |
Main stream supports |
| Vaizdo sparta |
32 Kbps to 8 Mbps |
| Maks. raiška |
2560 × 1440 |
| Pagrindinio srauto kadrai per sek. |
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
| Antrinio srauto kadrai per sek. |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Vaizdo nustatymai |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Dienos / nakties perjungimas |
Auto, scheduled |
| Tinklinis talpinimas |
Support Micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR |
| Pavojaus signalo sukėlimas |
Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login |
| Protokolai |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| API |
ONVIF (PROFILE S, PROFILE G), ISAPI |
| Pagrindinės fukcijos |
One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
| Ryšio sąsaja |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Reset mygtukas |
Yes |
| Veikimo sąlygos |
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing) |
| Maitinimas |
12 VDC ± 20%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
| Energijos suvartojimas |
12 VDC, 0.9 A, max. 11 W; PoE: (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, max. 12.9 W |
| IP apsaugos klasė |
IP67 |
| IR apšvietimas |
Up to 30 m |
| Išmatavimai |
Φ 105 mm × 244.4 mm (Φ 4.1″ × 9.6″) |
| Svoris |
Camera: approx. 1035 g (2.3 lb.) With package: approx. 1550 g (3.4 lb.) |
